Now everything that we have created in the previous stages must be recorded in the drawings, and the more details, the better. There will be fewer questions from builders. By the start of this stage, the drawings are already partially ready, since we are making some plans and unfolding of the walls for assigning to the visualizer. We need to complete the missing sections, check them thoroughly and put them together. In fact, this is the main part of the project, which will be a detailed guide for builders, and it needs to be given special attention. Many things are determined here, which, if not thought out, will then interfere with comfortable living. For example, an inconveniently located outlet / its absence or an illiterate distribution of light groups in the room. Working drawings are always developed in conjunction with the performers of ventilation and smart home, if any systems are available, since some nodes of their projects must be taken into account and combined with ours.
The standard set of drawings that are included in the design project looks like this: - measurement plan of the room - plan of demolished partitions - plan of the partitions to be erected - plan for the arrangement of furniture and equipment - plan for filling doorways - layout of plumbing equipment - layout of ventilation equipment - plan of arrangement of lighting fixtures with indication of groups - layout of switches indicating the inclusion of groups of luminaires - layout of electrical outlets and special connectors
- floor plan with coverage area, type of material used and level - plan of underfloor heating with binding of the regulator - plan of ceilings indicating dimensions, heights, type of material used and cuts - sweeps of the walls of the room with the application of structural elements, wiring products and decorative types of finishes, indicating the area of the selected material - drawings of furniture items, architectural elements and decor, made to order.
This stage requires 5-7 working days for development and 1-2 days for making changes. Drawings are developed by a leading designer and checked by a chief designer.
